Product Summary
The LM1117-ADJ is a positive adjustable and fixed regulator. It is designed to provide 1A with high efficiency. Its internal circuitry is designed to operate down to 1.3V input to output differential. On-chip trimming adjusts the reference voltage to 1%.
Parametrics
Absolute maximum ratings: (1)PD, Power Dissipation: Internally Limited W; (2)VIN, Input Voltage: 7V; (3)TJ, Operating Junction Temperature Range: Control Section: 0 to 125℃; Power Transistor: 0 to 150℃; (4)TSTG, Storage Temperature: -65 to 150℃; (5)TLEAD, Lead Temperature(Soldering, 10 sec): 300℃.
Features
Features: (1)Adjustable or Fixed Output; (2)Output Current of 1A; (3)Low Dropout, 1.3V max at 1A Output Current; (4)0.04% Line Regulation; (5)0.2% Load Regulation; (6)100% Thermal Limit Burn-in; (7)Fast Transient Response.
Diagrams
 |
